Pegler 38306 XPress Copper 54mm Elbow (M-Press) Pack of 1 - S12/7002A

Pegler Yorkshire VSH XPress Copper Elbow, 54mm, M-Press (38306 / S12/7002A)

This 54mm copper elbow forms part of the Pegler Yorkshire VSH XPress press-fit system, a leading solution for modern building services installations. Designed for fast, reliable jointing, it delivers heat-free installation that saves time, reduces labour costs, and eliminates the need for hot works permits.

The VSH XPress system provides a clean, efficient, and highly reliable joint, suitable for a wide range of applications including domestic, multi-occupancy, commercial, and public utility installations. Its versatility also extends to gas installations, with a comprehensive size range available to suit everything from small systems to large-scale developments.

Manufactured for exceptional performance, the fitting is BSI Kitemark approved (BS 8537:2010) and features the unique “Leak Before Press” function, ensuring any unpressed joints are clearly identified during pressure testing.

Key Features

• 54mm copper press-fit elbow (M-Press)

• Part of the Pegler Yorkshire VSH XPress system

• Heat-free press-fit jointing – no soldering or hot works

• Rapid installation saves time and labour

• Leak Before Press feature highlights unpressed joints

• Temperature rating from -20°C to 110°C

• Pressure rated to 16 bar across the temperature range

• Suitable for domestic, commercial, and public utility use

• Approved for gas installations

• BSI Kitemark certified to BS 8537:2010

A high-performance copper press fitting delivering fast, safe, and reliable joints across a wide range of building services applications.
